Double Side Heavy Duty Cantilever Racking System Long Arm Structure for Lumber Storage

1 / 5

Double Side Heavy Duty Cantilever Racking System Long Arm Structure for Lumber Storage

Still deciding? Get samples of $ !

Request Sample

Send Inquiry

Product Description

📋Basic Info.

Model NO. WD_CR_001

Usage Tool Rack, Tools, Industrial, Warehouse Rack

Material High Quality Cold-Rolled Steel

Structure Cantilever Rack

Type Cantilever Rack

Mobility Fixed

Height up to 32'

Weight up to 3900lbs (1769kg)

Closed Closed

Development Conventional

Serviceability Common Use

Design Service Free CAD Service Available

Back-up Service Installation Drawing/on Site Instruction

Container Load 15-18tons/1*20' Container, 20-25tons/1*40' Contain

Certification ISO9001

Transport Package Airbag; Air Bubble; Wooden Pallet, etc

Specification Customizable

Trademark As requested

Origin Nanjing

HS Code 73089000

Production Capacity 20000tons/Month

📦Product Description

What is Cantilever Racking?

Cantilever racking is a storage system designed specifically for long, bulky, or awkwardly shaped items that wouldn't work well on standard pallet racking systems. Unlike pallet racks, cantilever racks have no vertical posts in front, which creates a completely open storage area.

Benefits:

Unobstructed access: The lack of front columns allows for easy loading and unloading of long items using forklifts or other equipment.
Versatility: Cantilever racks can be configured in various ways to accommodate different sized items and storage requirements. You can have single-sided racks placed against walls or double-sided racks for maximized storage capacity.
Customizability: The arm levels can be adjusted along the uprights to fit the specific lengths of the items you're storing.

Specification

L_arm [in]	Static Capacity [lbs] Cantilever Column Per Side
L_arm [in]	36''	40''	48''	60''
H_column	W9.7
8'	14,000	14,000	14,000	14,000
12'	13,000	13,000	13,000	12,000
16'	12,000	12,000	12,000	10,000
20'	12,000	12,000	11,000	8,300
24'	8,800	6,600	-	-
28'	2,720	-	-	-
Column height can be up to 32'

L_arm [in]	Cantilever Arm Static Capacity [lbs]
L_arm [in]	36''	40''	48''	60''
Arm 4''	2,600	2,600	2,300	-
Arm 4.7''	3,300	3,300	3,300	2,900
Arm 5.5''	3,900	3,900	3,900	3,900

❓Frequently Asked Questions

What is the production capacity of the factory?

About 20,000 tons per month.

How long is the delivery time?

Delivery time depends on your package. Normally, the delivery time is 25 - 45 days. Depending on the quantity, we will calculate the most reasonable and fastest production and delivery time.

What products are exported?

Our main export product lines:
- Selective: teardrop/ tradition
- Cantilever: tradition
- ASRS - Radio Shuttle ASRS/ Crane-based ASRS/Four-way shuttle ASRS
- Double deep, Drive-in, VNA.
- Mezzanine
- Steel pallets, Powder coated pallets, Galvanized pallets, Hot dipped galvanized pallets.
- Processing details of mechanical equipment.

To which countries are the storage racks exported?

International standard storage racks are exported to global markets such as the US, Switzerland, Australia, Denmark, India, the Netherlands, Pakistan, Mauritius, and Southeast Asian countries such as Cambodia, Thailand, Indonesia, Singapore, Malaysia, etc.

What international trade transaction terms are offered?

EXW/FOB/CIF. All international transaction terms can be handled.

What are the payment terms?

Many different types of payment are offered. Depending on actual conditions and order value, reasonable payment conditions will be proactively offered to customers. Generally, our payment terms are 50% T/T in advance as a deposit, and 50% T/T against a copy of B/L as a balance.
